Aluminium Flush Casement Windows

Our contemporary aluminium casement window comes in a modernised flush design. The excellent performance of our traditional aluminium casement window has been matched with the traditional aesthetics of external flush contours. The flush casement comes with all the benefits you would expect from a highly engineered aluminium window design.

Material

With strength like no other material and a life-span measured in decades rather than years, aluminium has become the perfect choice for home owners. One of the main benefits of aluminium is its simple and straight forward maintenance, a simple wipe-down is all that’s required to keep your new windows looking their best.

Design

If you require elements of heritage but don’t want to lose out on the best possible performance, then our aluminium flush casements windows are the obvious choice. When closed the window sashes sit flush into the frame; this design is considered in-keeping with traditional windows as it imitates the construction of original timber windows.

  • Colours
  • Features
  • Hardware
  • Glass
  • Security
  • Shapes & Styles
White

White
RAL 9010

Grey

Grey
RAL 7016

Black

Black
RAL 9005

Cream

Cream
RAL 9001

Slate-Grey

Slate Grey
RAL 7015

Stone-Grey

Stone Grey
RAL 7030

White-Ali

White Ali
RAL 9006

ral-colours

Bespoke
Any RAL

Velour-white

Velour White
Sensations

Dune

Dune
Sensations

Sand

Sand
Sensations

Basque-red

Basque Red
Sensations

Chestnut-brown

Chestnut
Sensations

Silver-grey

Silver
Sensations

Provence-green

Provence
Sensations

Sky-blue

Sky Blue
Sensations

pic12

Standard Handle

Monkey Tail Gold

Monkey Tail Handle

Teardrop Chrome

Tear Drop Handle

Classic, traditional or contemporary? The choice is yours. Combine your choice of frame with your choice of matching hardware to create a solution that perfectly restores the balance and harmony of your home. The standard handle is available in 8 different finishes and the ironmongery monkey tail and tear drop ranges are available in chrome, gold, graphite and antique black.

white

White

black

Black

satin

Satin Chrome

chrome

Chrome

gold

Gold

Glass Options

standard glass window

The standard glass unit used in our aluminium flush windows is 24mm in depth and is comprised of 4mm clear glass to the outside, a warm edge spacer bar and 4mm clear Low E glass on the inside.

The inclusion of argon gas in to the cavity of a double-glazed unit reduces the heat conductance between the panes. This happens because the gas is 6 times denser that air.

Pilkington Optiphon is an acoustic laminated glass that offers excellent noise reduction without compromising on light transmittance or impact performance. Two 3mm pieces of glass are put together with a noise reducing interlayer typically 0.8mm thick. This glass offers the dual benefit of noise reduction and security.

Warm edge spacer bars insulate the edges of a sealed glass unit and separate the panes of glass. Traditionally, spacer bars were made of aluminium, however the warm edge spacer bar used in our glass units is an extruded PVC material specifically designed to reduce transference of heat between the panes of glass keeping more heat inside the property. The spacer bar is available in 3 different colours; grey, black and white.

Warm Edge Spacer Bars

Obscure Glass

Pilkington’s obscure glass range provides obscuration and decoration.  All patterns are classified according to their level of obscurity in relation to each other, with 1 being least obscure and 5 being most obscure.

Cassini
Level 5

Chantilly
Level 2

Charcoal Sticks
Level 4

Contora
Level 4

Digital
Level 3

Florielle
Level 4

Taffeta
Level 3

Everglade
Level 5

Mayflower
Level 4

Oak
Level 4

Pelerine
Level 4

Tribal
Level 5

Warwick
Level 1

Stippolyte
Level 4

Satin Glass
Level 5

PAS 24 Security Upgrade

Our aluminium windows come with the option to upgrade the security to our PAS 24:2016 security package. PAS 24 is a set standard with specifications as to which our aluminium windows have been tested against.

The PAS 24 upgrade includes:

  • Hinge Protectors
  • Anti Lifting Blocks

The upgrade is generally mandatory on new-build projects.

PAS24

Popular Window Styles

Please note that on flush styles, the window will always have a sash even when it’s non-opening. This allows the window to achieve what is known as equal sightlines.

c4:c5
c6
c11:c12
c14
c22
c48
c51
c40

Performance

Weather Performance

The flush casement window has not only been engineered to demonstrate a unique design, but also a top of the class weather performance. It comes with an extended cambered polyamide thermal break making it suitable for virtually all projects. Also, advanced weatherseals help keep your energy bills low and your home at the desired temperature all year round.

Energy Rating

It’s the well thought-through composition of the aluminium profile found beneath the external flush design that enables this window to achieve an outstanding energy rating of up to ‘A’. The aluminium flush casement windows enable you to get a solution that’s beautiful and performs inside out.

Guarantee

With all Quickslide aluminium flush casement windows, there is a 10-year manufacturing guarantee as standard. We strive to ensure that our quality is assured but having a 10-year guarantee offers peace of mind for years to come. Download our guarantee PDF or speak to one of product experts to find out more.

Security

Our aluminium windows have been security tested to PAS 24 enabling you to upgrade your window specification to meet the regulations for new-build projects. Utilising a multi-point locking mechanism, internal key locking handles and internal beads our aluminium windows offer the highest level of security as standard.

Technical Information

Key Measurements

Frame Depth: 70mm
Glazing: 24mm

Constraints

Side Hung Max Width: 700mm
Side Hung Max Height: 1400mm
Top Hung Max Width: 1400mm
Top Hung Max Height: 1300mm
